Specifications
Specifications-Basic Specs
PrintingMethod
Digital direct to garment printing
MachineSize
1400mm x 1300mm x 550mm
MachineWeight
Approx. 120kg
PlatenSizes
Maximum Print Size is 40,6cm x 53,3cm / 16” x 21”
IncludedPlatenSize
14” x 16” (35,6cm x 40,6cm)
InkType
Water-based innobella inks
InkHeadType
Brother On demand piezo head
NumberOfInkHeads
2 print heads / 8 ink channels
PrintResolution
1200 dpi x 1200 dpi
PrintMode
Single or double for CMYK. Underbase and highlight for white.
DataOutput
Printer driver (USB, File output)
PowerSupply
AC 100V-240V, 50/60Hz ± 1Hz
PowerConsumption
0.8A(average) (Reference: 0.3A - during circulation)
InkCure
Heat press machine can be used at 356°F (180°C) and 35 seconds duration. For higher volume production, a conveyor oven is recommended to be used at 320° (160°) for three and a half minutes. Time and temperature may vary depending on which manufacturer's dryer is used.
PreTreatment
Before printing, apply pre-treatment using either a manual or automatic device and then dry garment using a heat-press, being sure to follow all manufacturer's instructions. Pre-treatment is necessary for white ink only.
Specifications-Software
SupportedOS
Windows® 7(32 bit/64 bit), Windows 8.1(32 bit/64 bit), Windows 10(32 bit/64 bit), Mac OS® X v10.11.x
Interface
USB2.0, LAN(10 BASE-T, 100 BASE-TX), USB Flash Memory(Under 32GB, FAT32 format)
DriverOperatingConditions
2GHz CPU (minimum recommendation) 4GB RAM
DisplayResolution
XGA(1024x768) (minimum recommendation)
RecommendedApplications
Adobe® Photoshop CS6/CC, Adobe® Illustrator CS6/CC, CorelDRAW® 2018/2019 (Windows)
